Gondola Electromotion Window Cleaning Platform With Φ8.3 Steel Wire Rope

I'm Online Chat Now
Certification
China Jiangsu Shenxi Construction Machinery Co., Ltd. certification
China Jiangsu Shenxi Construction Machinery Co., Ltd. certification
Good quality, Good price and Service, Wish business grow better and better.

—— Savali- From Russia

Shenxi company does business and products with full passionate, they have full ability to do custom-made and research new products.

—— Rajan-From Brazil

Gondola Electromotion Window Cleaning Platform With Φ8.3 Steel Wire Rope

Gondola Electromotion Window Cleaning Platform With Φ8.3 Steel Wire Rope
Gondola Electromotion Window Cleaning Platform With Φ8.3 Steel Wire Rope Gondola Electromotion Window Cleaning Platform With Φ8.3 Steel Wire Rope

Large Image :  Gondola Electromotion Window Cleaning Platform With Φ8.3 Steel Wire Rope Get Best Price

Product Details:
Place of Origin: Wuxi, China
Brand Name: SHENXI
Certification: CE&SGS
Model Number: CW250
Payment & Shipping Terms:
Minimum Order Quantity: One set
Packaging Details: Nude and plywood case
Delivery Time: 20 Working Days
Payment Terms: T/T&L/C
Supply Ability: 15 sets per month
Detailed Product Description
High Light:

window cleaning equipment

,

window washing scaffold



Gondola Electromotion Window Cleaning Platform With Φ8.3 Steel Wire Rope





Descrition:

      In order to keep good appearance of the buildings permanently, it is necessary to clean and maintain the building facade, and gondola is the most safety, reliable and efficient equipment for the work. Our company is the birth-place of the first gondola in China. We can design and make various kinds of gondolas such as rail, suspension, and wheel, insert rod or sliding type according to the different kinds of building facades and roof structures and special needs from customers.





Parameters:

NO.

Name

Parameter

Remark

1

Gondola Lifting Speed

7-9m/min

Electromotion

2

Trolley Moving Speed

8m/min

Electromotion

3

Boom Slewing Speed

120º/min

Electromotion

4

Boom Rotation range

±180 °

Electromotion

5

Gondola Rotation Speed

360 º/min

Manual

6

GondolaRotation Range

±90 °



7

Gondola Lifting Height

120m/135m



8

Gondola Load Capacity

250kg

Can Load Two People

9

GondolaBasket Dimension

2600×700×1100mm



10

Steel Wire Rope

Φ8.3

Copper Core

11

Power

380v/3 phases /50hz



12

Total Weight

3500kgs/3500kgs



13

Prevent Rust Method

Hot-dip Galvanized



14

Installation Standards

GB19154-2003
